UMS 545 DC

Boat UMS 545 DC – light and comfortable vessel with two consoles and spacious cockpit. It offers maximum protection from weather conditions for driver and passenger. In the bow part there is even more place for fishing, hunting or baggage transportation comparing to 485 DC.



Παρουσίαση UMS 2024
.pdf
Λήψη PDF • 23.29MB

More information: https://www.esc.guide/ums



Characteristics

  • LOA, m: 5,07

  • BOA, m: 2,07

  • Maximum load, kg: 645

  • Deadrise, transome/middle, degree: 16/21,7

  • Hull thickness, board/bottom, mm: ¾

  • Passengers: 6

  • Transom height, mm: 510

  • Fuel tank, l: 77

  • Hull material: Aluminum alloy 5083

  • Design category: C


Engine

  • Maximum engine, h.p.: 115

  • Recommended engine, h.p.: 70

  • Maximum engine weight, kg: 190


Equipment

  • All-welded aluminum hull

  • Aluminum self-draining antiskid deck

  • Aluminum consoles of the driver and passenger with tempred glass and middle door

  • Cup-holder “UMS” (1 – driver console, 2 – passanger console, 1 – each bow seat)

  • U-shape bow seat

  • Aft seat

  • Anchor locker to the left from recess

  • Fuel system for 77 l. Indicator and sender included

  • Swim platforms (left and right)

  • Welded cleats – 4 pcs

  • Railings

  • Ladder “UMS”

  • Anode hull protection with mounting bracket – 2 pcs

  • Polyurethane foam inside the hull

  • Soft seat Premium Centurion on turnable pedestal with the slider Springfield 1240729-L – 2 pcs

  • Steering system (steering wheel, steering cable, non-reversable steering gear T73NRFC)

  • Control panel for the electric equipment

  • Electric socket 12 V with USB connector on driver’s console Navigational lights+musthead light

  • Automatic bilge pump

  • Bi-polar main switch

  • Battery container
